Vertical Milling Services
Tolerance Masters offer borth horizontal and vertical milling services up to full 5-axis capabilities.
Operating in a 25″ x 27″ x 60″ work envelope, we use high speed steel, carbide, carbon steel, and cobalt HSS cutting tools including flat end and ball end mills, chamfer, face, and twist mills, reamers and taps. Our machines feature spindles and chucks, with variable spindle speeds, power-operated table feeds, and high-speed machining.
We are experienced in 3D part modeling for prototypes and specialty jobs. Some typical products we mill include turbine, hydraulic components, and other cubed products. Contact us today to learn more about our milling capabilities.
VERTICAL MILLING SPECIFICATIONS
Intended Applications
| Machine components Engine components Turbine components Hydraulic components Turbomachinery components Construction equipment Shafts Forgings Valves |
Pins Thread rod Fasteners Spindles Sockets Bushings Spacers Fittings Standoffs |
Vertical Milling Processes
| Drilling Boring Counterboring Countersinking |
Pocketing Profiling Reaming Tapping |
Materials (Metals)
| Alloy Steels Aluminum Beryllium Brass Bronze Alloys Carbide Carbon Steel Cobalt Copper Iron Lead |
Magnesium Molybdenum Monel Nickel Palladium Stainless Steel Tin Titanium Tungsten Zinc |
Materials (Plastic Polymers)
| ABS (Acrylonitrile Butadiene Styrene) Acetal Acrylic Fiberglass Reinforced Plastics Nylon Phenolic Polyamide-Imide Polycarbonate Polyetheretherketone (PEEK) |
Polyetherimide Polyethylene Polyphenylene Sulfide Polypropylene Polystyrene Polysulphone PTFE (PolyTetraFluoroEthylene) PVC (Polyvinyl Chloride) PVDF (Polyvinylidene Fluoride) |
Type of Milling Machines
| Vertical Machining Centers |
Cutters
| Flat end mill Ball end mill Chamfer mill Face mill |
Twist mill Reamer Tap |
Cutting Tools
| High-speed steel (HSS) Carbide |
Carbon Steel Cobalt High Speed Steel |
Axes
| 5 |
Type of Collet / Adapter
| Spindle- have a standardized spindle end Chuck- used to attach chucks to milling machines having a standard spindle end |
Vise
| Plain Swivel-type |
Equipment Capabilities
| Direct Electric-drive motors Coolant systems Variable spindle speeds |
Power-operated table feeds High speed machining Up to 1800 spindle |
Tolerance (+/-)
| .001″ Position, ± .001″ Profile |
Length
| Max: 60 in |
Width
| Max: 27 in |
Height
| Max: 25 in |
Production Volume
| Prototypes that Lead into Program Production Low Volume Batch Lots |
Small Run Medium to Large Scale Production Volume Run |
Efficiency
| Lights Out Manufacturing Lean Manufacturing |
Additional Information
Industry Focus
| Aerospace Dental Machine Tool Marine Medical |
Military Optical Packaging / Converting Pharmaceutical |
Industry Standards
| ASTM AS9100D Aerospace Industry Standard |
ISO 9001:2008 International Organization for Standardization |
File Format
| .asm .bmp .CATPart .CATProduct .cgr .ckd .ckt .csv .dib .dwg .dxf .exp .gif .hmf .hsf .iges .igs .ipt .jpg .KVTSession CAD |
.mod .model .obj .pm .prt .ptn .sab .sat .session .sldprt .srf .step .stl .stp .tif .u3d .xmt_text x_b x_t xmt_bin |
