Wire EMD Machining
With a focus on unique metal geometries, Tolerance Masters offers wire EDM machining services.
With a focus on unique metal geometries, Tolerance Masters offers wire EDM machining services. Materials that we specialize in include carbides, titanium, high temperature steels, and other metals like cobalt and carbon steel. Our wire EDMs feature CNC 3-axis capabilities, with a maximum material thickness of 4″ and a bed size of 20″ x 10″ X 12″.
Tyipcal EDM applications include kidney pocket shaped configurations, tight hole shapes and slots. We are able to utilize down to .004″ wire diameter, but most commonly use .008″ to .010″ wire size. Contact us for a quote on any job, from a prototype or short run, up to a large scale production order.
WIRE EMD MACHINING SPECIFICATIONS
Processes
| Wire Electrodischarge Machining (EDM) |
Equipment Capabilities
| CNC Control Capabilities Coordinate Measuring Machines (CMM) |
Lead Times Available
| Quoted on job by job basis |
Production Volume
| Specialty Production Shop Prototype Low Volume Small Run |
High Volume Large Run Long Run Large Scale Production Volume Run |
Additional Capabilities
| CAD Design Services CAM Programming Services Complex Component |
Honeycomb Machining Glass Scales High Speed Wire Feed |
Materials (Metals)
| Alloy Steels Aluminum Brass Bronze Alloys Carbide Carbon Steel Cobalt Copper Iron |
Lead Magnesium Molybdenum Nickel Palladium Stainless Steel Tin Titanium Tungsten |
Wire Diameter
| .004″ up to .010″ |
Material Thickness
| Max: 40 in |
Bed Length
| Max: 4 in |
Bed Width
| 20″ X height 20″ X 10″ |
Additional Information
Intended Application
| Machine components Engine components Turbine components Hydraulic components Turbomachinery components Construction equipment Shafts Forgings Valves Valve Bodies Pins Thread rod |
Liners Spindles Sockets Bushings Spacers Fittings Standoffs Extrusion Dies Fixtures Form Tools Injection Mold Components |
Industry Standards
| ASTM AS9100D Aerospace Industry Standard |
ISO 9001:2008 International Organization for Standardization |
File Format
| .asm .bmp .CATPart .CATProduct .cgr .ckd .ckt .csv .dib .dwg .dxf .exp .gif .hmf .hsf .iges .igs .ipt .jpg .KVTSession CAD |
.mod .model .obj .pm .prt .ptn .sab .sat .session .sldprt .srf .step .stl .stp .tif .u3d .xmt_text x_b x_t xmt_bin |
